TouchPad cable
Description Spare part number
TouchPad cable 856008-001
Before removing the TouchPad cable, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 34).
Remove the TouchPad cable:
1. Turn the keyboard/top cover upside down with the front toward you.
2. Release the tape (1) that secures the TouchPad cable ZIF connector.
3. Release the ZIF connector (2) to which the TouchPad cable is attached, and then disconnect
the TouchPad cable (3) from the TouchPad.
4. Remove the TouchPad cable.
Reverse this procedure to install the TouchPad cable.
Component replacement procedures 39
