USB port shield
Description Spare part number
Shielding Kit (includes memory module shield and USB port shield) 856014-001
Before removing the USB port shield, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 34).
5. Remove the battery (see Battery on page 42).
Remove the USB port shield:
1. Remove the adhesive strip (1) that secures the USB port shield to the base enclosure.
2. Remove the USB port shield (2).
Reverse this procedure to install the USB port shield.
50 Chapter 5 Removal and replacement procedures for authorized service provider parts
