Hard drive or solid-state hard drive
NOTE: The mounting brackets and the hard drive/solid-state drive cable are not included in the drive spare
part kit. The hard drive/solid-state drive cable is available using spare part number 856011-001. The hard
drive mounting bracket is available using spare part number 856012-001. The solid-state drive mounting
bracket is available using spare part number 856013-001.
Description Spare part number
Solid-state drive (128-GB, M.2 SATA, DRAM-less) 827560-011
Hard drives:
1-TB, 5400-rpm, 7.2-mm hard drive (for use only on computer models with model numbers m3-u000
through m3-u099 and m13-u000 through m13-u099)
832077-005
500-GB, 5400-rpm, 7.2-mm hard drive (for use on all computer models) 778186-005
500-GB, 5400-rpm, 7.0-mm solid-state hard drive with 8-GB NAND (for use on all computer models) 732000-005
Before removing the hard drive or solid-state drive, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 34).
5. Remove the battery (see Battery on page 42).
Remove the mass storage device:
1. Release the ZIF connector (1) to which the mass storage device cable is attached, and then disconnect
the mass storage device cable from the system board.
2. Remove the four Phillips PM2.0×4.6 screws (2) that secure the mass storage device to
the base enclosure.
3. Lift the right edge of the mass storage device (3) until it rests at an angle.
Component replacement procedures 43
