HP ProBook 4525s - Notebook PC User Manual

12. Slide the keyboard back toward the display (1), and then rotate it forward (2) to gain access to the
keyboard cable connector.
NOTE: Refer to the illustration that most closely matches your computer.
CAUTION: Do not rip the keyboard cable.
– or –
Slide the keyboard back toward the display (1), and then rotate it to the right side (2) to gain access
to the keyboard connector.
CAUTION: Do not rip the keyboard cable.
13. If you are replacing a memory module, remove the existing memory module:
CAUTION: To prevent damage to the memory module, hold the memory module by the edges
only. Do not touch the components on the memory module.
a. Pull away the retention clips (1) on each side of the memory module.
The memory module tilts up.
Adding or replacing memory modules 69

HP ProBook 4525s - Notebook PC Specifications

General

Chipset	AMD M880G
Memory	Up to 8 GB DDR3
Graphics	ATI Mobility Radeon HD 4250
Operating System	Windows 7 Professional
Wireless	802.11b/g/n
Webcam	2 MP webcam
Processor	AMD Turion II Dual-Core Mobile Processor, AMD Athlon II Dual-Core Processor
Display	15.6-inch diagonal LED-backlit HD anti-glare
Storage	320 GB
Optical Drive	DVD+/-RW SuperMulti DL LightScribe
Battery	6-cell Lithium-Ion
Bluetooth	Yes
Audio	Integrated stereo speakers
Ports	3 USB 2.0
