HP ProBook 4525s - Notebook PC User Manual

17. Place the switch cover on top of the switch cover tray (1), and then slide the switch cover into place
(2).
18. Close the computer display.
19. Turn the computer upside down on a flat surface, with the battery bay toward you.
20. Replace the 2 screws (1) and their covers (2) on the back edge of the computer.
NOTE: Some models do not have any screws or screw covers to replace.
74 Chapter 8 Memory modules

HP ProBook 4525s - Notebook PC Specifications

General

Chipset	AMD M880G
Memory	Up to 8 GB DDR3
Graphics	ATI Mobility Radeon HD 4250
Operating System	Windows 7 Professional
Wireless	802.11b/g/n
Webcam	2 MP webcam
Processor	AMD Turion II Dual-Core Mobile Processor, AMD Athlon II Dual-Core Processor
Display	15.6-inch diagonal LED-backlit HD anti-glare
Storage	320 GB
Optical Drive	DVD+/-RW SuperMulti DL LightScribe
Battery	6-cell Lithium-Ion
Bluetooth	Yes
Audio	Integrated stereo speakers
Ports	3 USB 2.0
