Item Description Spare part number
(1) Display panel assembly
NOTE: Displays are spared only at the subcomponent level. Display assemblies are not spared as
whole units.
not spared
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 41.
No backlight L01028-xxx
Backlit L01027-xxx
(3) Top cover L00844-001
(4) Power button board L00832-001
(5) TouchPad L00846-001
(6) Speaker assembly L00838-001
(7) Battery, Li-ion (4-cell, 48 WHr, 4.21 Ah) 851610-855
(8) Fingerprint reader assembly (includes cable) L00851-001
(9) Fan L00843-001
(10) Heat sink assembly (includes replacement thermal material) L20773-001
(11) RTC battery 746439-001
(12) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
AMD A10-9620P processor L15821-xxx
AMD A9-9420 processor L15822-xxx
(13) Power connector cable L01952-001
(14) USB board L00831-001
(15) Card reader board L00833-001
(16) Base enclosure L00849-001
(17) Hard drive
1 TB, 5400 rpm, 7 mm 762990-001
500 GB, 7200 rpm, 7 mm 703267-001
(18) Hard drive cover
NOTE: The hard drive cover is included in the Hard Drive Hardware Kit.
L00836-001
(19) Memory modules
8-GB (DDR4-2133) 820570-001
4-GB (DDR4-2400) 862397-850
(20) WLAN module
Computer major components 17
