Battery
Description Spare part number
Battery, 4-cell, 48 WHr, 4.21 Ah 851610-855
Before removing the battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Place the computer in “Battery Safe mode” (Battery Safe mode on page 31).
3. Disconnect all external devices connected to the computer.
4. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
5. Remove the following components:
a. Service doors (Service doors on page 32).
b. Hard drive (Hard drive on page 38)
c. Keyboard (Keyboard on page 41)
d. Top cover (Top cover on page 45)
e. Card reader board (Card reader board on page 59)
To remove the battery:
1. Position the computer upright on a at surface and open the display as far as possible.
2. Remove the 3 Torx T8 2.5×5.0 screws (1) that secure the battery to the computer.
60 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
