Item Description Spare part number
Realtek RTL8822BE 802.11AC 2x2 Wi-Fi + BT 4.2 Combo Adapter 915623-001
Realtek RTL8821CE 802.11AC 1x1 Wi-Fi + BT 4.2 Combo Adapter 915621-001
(21) M.2 solid-state drive
256-GB, PCIe, NVMe L15827-001
128-GB, SATA-3, TLC L15826-001
(22) Main service door
NOTE: The main service door is included in the Plastic Kit.
L00834-001
(23) Drive service door
NOTE: The drive service door is included in the Hard Drive Hardware Kit.
L00836-001
Cable Kit
Item Description Spare part number
Cable Kit L00847-001
(1) TouchPad cable
(2) Power button board cable
(3) Card reader board cable
(4) USB board cable
18 Chapter 3 Illustrated parts catalog
