3. Disconnect the display cable (2), and then remove the display cable from the clips in the fan (3).
4. Remove the Torx T8 2.5×5.0 screw (1) that secures the fan to the computer.
5. Lift the fan out of the computer (2).
NOTE: The fan bracket is available using spare part number L01029-001.
Reverse this procedure to install the fan.
58 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
