HP ProBook 6450b - Notebook PC User Manual

Replacing a hard drive in the hard drive bay
CAUTION: To prevent information loss or an unresponsive system:
Shut down the computer before removing the hard drive from the hard drive bay. Do not remove the
hard drive while the computer is on, in the Sleep state, or in Hibernation.
If you are not sure whether the computer is off or in Hibernation, turn the computer on by briefly pressing
the power button. Then shut down the computer through the operating system.
To remove a hard drive:
1. Save your work.
2. Shut down the computer and close the display.
3. Disconnect all external hardware devices connected to the computer.
4. Unplug the power cord from the AC outlet.
5. Turn the computer upside down on a flat surface, with the battery bay toward you.
6. Remove the battery from the computer.
7. Loosen the 2 hard drive cover screws (1).
8. Remove the hard drive cover (2).
9. Loosen the hard drive screws (1).
10. Pull the hard drive tab to the right (2) to disconnect the hard drive.
Replacing a hard drive in the hard drive bay 83

HP ProBook 6450b - Notebook PC Specifications

General

Processor	Intel Core i5 or i7
RAM	Up to 8 GB DDR3
Operating System	Windows 7 Professional
CPU	Intel Core i5 or i7
Storage	Up to 500GB HDD or 256GB SSD
Display	14.0-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Graphics	Intel HD Graphics
Battery	6-cell Li-ion
Chipset	Intel QM57
Optical Drive	DVD+/-RW SuperMulti DL
Wireless	802.11a/b/g/n
Audio	Stereo speakers, microphone
Ports	DisplayPort, VGA, RJ-45
Card Reader	5-in-1
Webcam	2 MP Webcam (optional)
