Removal and replacement procedures
Maintenance and Service Guide 4–45
Display assembly
The display assembly spare part kit includes 3 WLAN antenna transceivers and cables, microphones, nameplate,
and logo.
Description Spare part number
For use only with HP Compaq 6545b computer models:
15.6-in, HD+, LED, WVA display assembly for use only with computer models equipped with a
webcam and WWAN functionality (includes 2 WWAN antenna transceivers and cables)
584230-001
15.6-in, HD+, LED, WVA display assembly for use only with computer models equipped with
WWAN functionality but not equipped with a webcam (includes 2 WWAN antenna transceivers
and cables)
584229-001
15.6-in, HD+, LED, AntiGlare display assembly for use only with computer models equipped with
a webcam
583225-001
15.6-in, HD+, LED, AntiGlare display assembly for use only with computer models not equipped
with a webcam
583222-001
15.6-in, HD, LED, WVA display assembly for use only with computer models equipped with a
webcam (includes 2 WWAN antenna transceivers and cables)
584228-001
15.6-in, HD, LED, WVA display assembly for use only with computer models not equipped with a
webcam (includes 2 WWAN antenna transceivers and cables)
584227-001
15.6-in, HD, LED, AntiGlare display assembly for use only with computer models equipped with
a webcam
583223-001
15.6-in, HD, LED, AntiGlare display assembly for use only with computer models not equipped
with a webcam
583220-001
For use only with HP Compaq 6540b computer models:
15.6-in, HD, LED, AntiGlare display assembly for use only with computer models equipped with a
webcam and WWAN functionality (includes 2 WWAN antenna transceivers and cables)
594005-001
15.6-in, HD, LED, AntiGlare display assembly for use only with computer models equipped with
WWAN functionality but not a webcam (includes 2 WWAN antenna transceivers and cables)
594004-001
15.6-in, HD, LED, AntiGlare display assembly for use only with computer models equipped with a
webcam but not equipped with WWAN functionality
593996-001
15.6-in, HD, LED, AntiGlare display assembly for use only with computer models not equipped
with a webcam or with WWAN functionality
593995-001
15.6-in, HD+, LED, WVA, AntiGlare display assembly for use only with computer models not
equipped with a webcam or with WWAN functionality
593999-001
15.6-in, HD+, LED, WVA, AntiGlare display assembly for use only with computer models
equipped with WWAN functionality but not a webcam (includes 2 WWAN antenna transceivers
and cables)
594002-001
15.6-in, HD+, LED, WVA, AntiGlare display assembly for use only with computer models
equipped with a webcam but not equipped with WWAN functionality
594003-001
15.6-in, HD+, LED, WVA, AntiGlare display assembly for use only with computer models
equipped with a webcam and WWAN functionality (includes 2 WWAN antenna transceivers
and cables)
594006-001
15.6-in, HD, LED, BrightView display assembly for use only with computer models equipped with
a webcam and WWAN functionality (includes 2 WWAN antenna transceivers and cables)
594001-001
15.6-in, HD, LED, BrightView display assembly for use only with computer models equipped with
WWAN functionality but not a webcam (includes 2 WWAN antenna transceivers and cables)
594000-001
(Continued)
