External component identification
Maintenance and Service Guide 2–5
Pointing devices
Item Component Description
(1) Pointing stick (select models only)* Moves the pointer and selects or activates items on the screen.
(2) Left pointing stick button (select
models only)*
Functions like the left button on an external mouse.
(3) TouchPad* Moves the pointer and selects or activates items on the screen.
(4) Left TouchPad button* Functions like the left button on an external mouse.
(5) Right pointing stick button* Functions like the right button on an external mouse.
(6) TouchPad scroll zone Scrolls up or down.
(7) Right TouchPad button* Functions like the right button on an external mouse.
*This table describes factory settings. To view or change pointing device preferences:
■ In Windows 7 and Windows Vista: Select Start > Control Panel > Hardware and Sound > Mouse.
■ In Windows XP: Select Start > Control Panel > Printers and Other Hardware > Mouse.
