3–14 Maintenance and Service Guide
Illustrated parts catalog
(22) Base enclosure (includes 7 rubber feet):
For use only with HP Compaq 6540b and 6545b computer models 598205-001
For use only with HP Compaq 6440b and 6445b computer models 598206-001
Latch Kit (not illustrated, includes battery eject arm, latch, and spring) 583239-001
Rubber Kit (not illustrated, includes 7 rubber feet, 2 base enclosure screw covers, and
8 display bezel screw covers)
583280-001
(23) Battery:
9-cell, 93-WH battery for use with all computer models 586031-001
6-cell, 55-WH battery for use only with HP Compaq 6545b and 6445b computer models 482962-001
For use only with HP Compaq 6540b and 6440b computer models:
■ 6-cell, 55-WH battery 486296-001
■ 6-cell, 47-WH battery 486295-001
(24) Optical drive (includes bezel and bracket):
Blu-ray ROM with LightScribe DVD±RW SuperMulti Double-Layer Drive 583248-001
DVD±RW and CD-RW SuperMulti Double-Layer Drive 583250-001
DVD-ROM Drive 583249-001
MultiBay hard drive carrier (not illustrated) 583251-001
MultiBay hard drive carrier - halogen free (not illustrated) 614947-001
(25) Mass storage device:
Hard drive (includes bracket):
■ 500-GB, 7200-rpm 583246-001
■ 500-GB, 7200-rpm for use only with HP Compaq 6545b and 6445b models 614952-001
■ 500-GB, 7200-rpm for use only with HP Compaq 6540b and 6440b models 614953-001
■ 320-GB, 7200-rpm for use only with HP Compaq 6540b and 6440b models 615595-001
■ 250-GB, 7200-rpm 583244-001
■ 160-GB, 7200-rpm 583243-001
Solid-state drive (includes bracket):
■ 160-GB, 2.5-in solid-state drive—for use only with HP Compaq 6540b and 6440b
computer models
598089-001
■ 128-GB, 2.5-in solid-state drive—for use with all computer models 583247-001
(26) Bluetooth module 537921-001
✎
The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth module cable is
included in the Cable Kit, using the following spare part numbers:
❐ 583282-001—for use only with HP Compaq 6545b computer models
❐ 593853-001—for use only with HP Compaq 6540b computer models
❐ 583957-001—for use only with HP Compaq 6445b computer models
❐ 593854-001—for use only with HP Compaq 6440b computer models
✎
See “Cable Kit” on page 3-18 for more Cable Kit spare part information.
(27) HSPA EV-DO WWAN module 531993-001
(Continued)
Item Description Spare part number
