3–20 Maintenance and Service Guide

Illustrated parts catalog

Item Description Spare part number

(1) Display bezel:

For use only with HP Compaq 6545b computer models equipped with a webcam 583235-001

For use only with HP Compaq 6545b computer models not equipped with a webcam 583236-001

For use only with HP Compaq 6540b computer models equipped with a webcam 593847-001

For use only with HP Compaq 6540b computer models not equipped with a webcam 593848-001

For use only with HP Compaq 6445b computer models equipped with a webcam 583237-001

For use only with HP Compaq 6445b computer models not equipped with a webcam 583238-001

For use only with HP Compaq 6440b computer models equipped with a webcam 593849-001

For use only with HP Compaq 6440b computer models not equipped with a webcam 593850-001

(2) Webcam module 583219-001

(3) Display Hinge Kit (includes left and right hinges)

For use only with HP Compaq 6545b and 6540b computer models 583232-001

For use only with HP Compaq 6445b and 6440b computer models 583959-001

Display Cable Kit:

For use only with HP Compaq 6545b and 6540b computer models equipped with an

HD+ display assembly

583956-001

For use only with HP Compaq 6545b and 6540b computer models equipped with an

HD display assembly

583230-001

For use only with HP Compaq 6445b and 6440b computer models equipped with an

HD+ display assembly

593990-001

For use only with HP Compaq 6445b and 6440b computer models equipped with an

HD display assembly

583231-001

Includes:

(4) Display panel cable and webcam cable

(5) WLAN antenna transceivers and cables

(6) Microphones and cables

(7) WWAN antenna transceivers and cables

(8) Display enclosure (includes 3 WLAN antenna transceivers and cables, and 2 WWAN antenna transceivers

and cables)

For use only with HP Compaq 6545b computer models equipped with two microphones 583278-001

For use only with HP Compaq 6545b computer models equipped with one microphone 583233-001

For use only with HP Compaq 6540b computer models equipped with two microphones 593843-001

For use only with HP Compaq 6540b computer models equipped with one microphone 593844-001

For use only with HP Compaq 6445b computer models equipped with two microphones 583955-001

For use only with HP Compaq 6445b computer models equipped with one microphone 583234-001

For use only with HP Compaq 6440b computer models equipped with two microphones 593845-001

For use only with HP Compaq 6440b computer models equipped with one microphone 593846-001
