Switch Overview
Switch Hardware Features
LEDs
The front panel of the switch provides status LEDs for system
monitoring. The following table details the functions of the various
indicators.
System LED State Meaning
Power
(green)
On The switch is receiving power.
Off The switch is NOT receiving power.
Port LED State Meaning
Link/Act
(green –
overlaid with
the port
number)
On The port is enabled and receiving a link indication
from the connected device.
Off The port has no active network cable connected,
or is not receiving link signal.
Flashing Indicates that there is network activity on the
port.
FDx
(green)
On Indicates the port is operating at full duplex.
Off Indicates the port is operating at half duplex.
Spd
(green)
On Ports 1-8: Indicates the port is operating at
1000 Mbps.
Off Ports 1-8: Indicates the port is operating at 10 or
100 Mbps.
