HP ProCurve 2610 Installation And Getting Started Guide

Index – 5
Index
switch
connecting to a power source … 2-16
description … 1-1
downloading new software … 4-13
electrical specifications … A-1
environmental specifications … A-2
features … 1-12
front panel description … 1-4
included parts … 2-1
LED descriptions … 1-5
mounting in a rack or cabinet … 2-9
mounting on a wall … 2-14
mounting on horizontal surface … 2-15
physical specifications … A-1
switch operation
verifying after installation … 2-6
Switch Setup screen … 3-2
configuring a subnet mask … 3-2
configuring an IP address … 3-2
field descriptions … 3-3
switch specifications … A-1
T
technology distance specifications … B-2
Telnet access to the console … 3-5
terminal configuration … 2-26
testing
checking the console messages … 4-10
checking the LEDs … 4-10
diagnostic tests … 4-10
end-to-end communications … 4-11
link test … 4-11
Ping test … 4-11
switch operation … 4-10
switch-to-device communications … 4-11
twisted-pair cabling … 4-11
tips for troubleshooting … 4-1
topologies
effects of improper topology … 4-2
samples of … 2-28, 2-32
troubleshooting … 4-1
basic tips … 4-1
checking port configuration … 4-3
checking the console messages … 4-10
checking the LEDs … 4-10
common network problems … 4-1
connecting to fixed full-duplex devices … 4-1
diagnostic tests … 4-10
effects of improper topology … 4-2
effects of non-standard cables … 4-2
link test … 4-11
Ping test … 4-11
Proactive Network tools … 4-9
restoring factory default configuration … 4-12
testing connections to other devices … 4-11
testing end-to-end communications … 4-11
testing the switch … 4-10
testing the twisted-pair cables … 4-11
twisted-pair cable
cross-over cable pin-out … B-7
pin-outs … B-4, B-6, B-8
straight-through cable pin-out … B-6, B-8
switch-to-computer connection … B-6, B-8
switch-to-switch or hub connection … B-7
testing … 4-11
twisted-pair ports
HP Auto-MDIX feature … B-4
V
VT-100 terminal
serial cable connection for … 2-27
W
wall
mounting switch on … 2-14
wiring rules for twisted-pair cables … B-5

HP ProCurve 2610 Specifications

General

Switching Capacity	12.8 Gbps
Forwarding Rate	9.5 Mpps
MAC Address Table Size	8000 entries
Layer	Layer 2
RAM	64 MB
Flash Memory	16 MB
Jumbo Frame Support	Yes
Manageable	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 x 10/100
VLANs	256
Management	Web, CLI, SNMP
Power Supply	Internal
Operating Temperature	0°C to 40°C
Dimensions (W x D x H)	17.42 x 12.73 x 1.73 in
