2-18
Installing the Series 5400zl Switches
Installation Procedures
Installing the Series 5400zl
Switches
6. Install the Grounding Wire
If a grounding wire is to be attached to the switch chassis, the grounding lug
must be removed and a wire crimped to it and the grounding lug must be
reinstalled.
1. Use a #1 Phillips (cross-head) screwdriver and remove the grounding lug
and two screws from the back of the switch.
2. Crimp the grounding lug to a properly grounded grounding wire.
3. Re-attach the grounding lug to the switch with the two screws.
Figure 2-11. Attaching Grounding Lug to the 5400zl Switch
Grounding
lug screws
Grounding
lug screws
