A-1
Specifications
A
Specifications
Physical
Electrical
The Series 5400zl Switches automatically adjust to any voltage between
100-127 and 200-240 volts when using the J8712A power supply, and 200-240
volts only when using the J8713A power supply, and either 50 or 60 Hz.
Width: 44.2 cm (17.2 in)
Depth: 45.0 cm (17.6 in)
Height: 17.5 cm (6.8 in)
Weight:
• Switch 5400zl
• Switch 5406zl
• 17.5 kg (38.58 lbs)
• 24.5 kg (54.01 lbs) – includes two modules
J8712A J8713A
AC voltage: 100–127 volts 200–240 volts 200–240 volts only
Maximum current: 11.5 A 5.7 A 10 A
Frequency range: 50/60 Hz 50/60 Hz 50/60 Hz
Maximum continuous
output power:
875W 875W 1500W
Each installed module may draw 369.6W@50V for PoE
