2-23
Installing the Switch
Sample Network Topology
Installing the Switch
In such a model, server/access layer network infrastructure can be completely
standardized and continuously deployed without regard to application
requirements.
Figure 2-19. Example topology
Servers
Gigabit fiber cable
ProCurve Switch 6600
Servers
Servers
Servers
Gigabit fiber cable
ProCurve Switch 6600
