Spare part
number
Description
702084-001 Nvidia GeForce GT630 DP PCIe x16 graphics card, 2 GB
703372-001 HP Ultraslim Keyed Cable Lock
703597-001 Hard drive carrier, 2.5-inch to 3.5-inch
707252-001 Nvidia NVS310 PCIe x16 graphics card, 512 MB
709695-xx1 Keyboard, unbranded
712298-001 Power supply for use in the microtower, 300W, Energy Star 5.0
715184-001 Power supply for use in the microtower, 300W, Active PFC
715185-001 Power supply for use in the microtower, 300W, regular
716390-001 Card reader, 14-in-1, USB 3.0, 3.5-inch, UHS-I
717219-001 AMD Radeon HD8490 DP PCIe x16 graphics card, 1 GB
717220-001 AMD Radeon HD8350 DH PCIe x16 graphics card, 1 GB DDR3
718412-001 System board for use in 490 models without Windows 8 (includes replacement thermal material)
718412-501 System board for use in 490 models with Windows 8 Standard (includes replacement thermal material)
718412-601 System board for use in 490 models with Windows 8 Professional (includes replacement thermal material)
718413-001 System board for use in 400 models without Windows 8 (includes replacement thermal material)
718413-501 System board for use in 400 models with Windows 8 Standard (includes replacement thermal material)
718413-601 System board for use in 400 models with Windows 8 Professional (includes replacement thermal material)
719901-001 Mouse, USB, Portia
720216-001 Adapter, DVI-I to VGA (BFR/PVC free)
720837-001 Nvidia NVS315 PCIe x16 graphics card, 1 GB
724718-xx1 Keyboard, PS/2, for use in models with Windows 8
724720-xx1 Keyboard, USB, black, for use in models with Windows 8
724722-201 Keyboard, wireless, HP Elite with USB dongle (for use only in Brazil)
724795-001 Mouse, washable
724937-001 1 TB hard drive, hybrid SSD
724938-001 500 GB hard drive, hybrid SSD
727373-001 Intel Core i7 4770 processor (3.4-GHz, 8-MB L3 cache)
727380-001 Intel Core i5 4570 processor (3.2-GHz, 6-MB L3 cache)
727381-001 Intel Core i5 4670 processor (3.4-GHz, 6-MB L3 cache)
728562-001 Intel PRO/1000 single port GbE NIC, includes bracket
729084-001 AMD Radeon HD8350 PCIe x16 graphics card, 1 GB (for use only in the People’s Republic of China)
729085-001 AMD Radeon HD8470 PCIe x16 graphics card, 2 GB (for use only in the People’s Republic of China)
Microtower chassis spare parts
21

HP ProDesk 490 G1 Specifications

General

Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	8 MB
Processor cores	4
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Desktop series
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory voltage supported by processor	1.5 V
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	4x DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Maximum internal memory	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	1000 GB
Intel segment tagging	Enterprise, Small Business
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
On-board graphics card ID	0x412
Discrete graphics card model	NVIDIA® GeForce® GT 630
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2048 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	2 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
Bundled software	HP Client Security\\r HP Trust Circles Standard\\r HP Wireless HotSpot\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r CyberLink PowerDVD\\r CyberLink Power2Go\\r Buy Office
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Audio system	Realtek ALC221
Product type	PC
Motherboard chipset	Intel® H87
Scalability	1S
Processor code	SR149
Processor ARK ID	75122
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00
Power supply	300 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	402 mm
Width	182.8 mm
Height	357 mm
Weight	7140 g
