HP ProDesk 490 G1 User Manual

Spare part
number
Description
729339-001 Keyboard, USB, unbranded, Katydid
730323-xx1 Wireless keyboard, mouse, and dongle kit (for use in all countries except for Brazil)
732505-001 Intel Core i5 4570s processor (2.9-GHz, 6-MB L3 cache), 65W
732506-001 Intel Core i5 4670s processor (3.1-GHz, 6-MB L3 cache), 65W
732507-001 Intel Core i7 4770s processor (3.1-GHz, 6-MB L3 cache), 65W
735966-001 DisplayPort connector module (for use only in 480 MT and 490 MT models)
736299-001 Card reader, 15-in-1, USB 3.0, 3.5-inch, UHS-II
736835-001 Adapter, USB 3.0 to 2.0
742560-001 Intel Core i3 4130 processor (3.4-GHz, 4-MB L3 cache), 54W
742561-001 Intel Core i3 4330 processor (3.5-GHz, 4-MB L3 cache), 54W
742562-001 Intel Core i3 4340 processor (3.6-GHz, 4-MB L3 cache), 54W
742563-001 Intel Core i7 4771 processor (3.5-GHz, 8-MB L3 cache), 84W
742564-001 Intel Pentium G3220 processor (3.0-GHz, 3-MB L3 cache), 54W
742565-001 Intel Pentium G3420 processor (3.2-GHz, 3-MB L3 cache), 54W
742566-001 Intel Pentium G3430 processor (3.3-GHz, 3-MB L3 cache), 54W
745033-001 Intel Core i5 4430 processor (3.0-GHz, 6-MB L3 cache), 84W
745034-001 Intel Core i5 4430s processor (2.7-GHz, 6-MB L3 cache), 65W
745036-001 Optical drive bezel blank
745046-001 Access panel
745047-001 Front bezel for use in all countries and regions except for the People’s Republic of China
745048-001 Front bezel for use in the People’s Republic of China
745049-001 Front I/O assembly
745050-001 Power switch/LED with holder
745051-001 SATA data cable, 14 inch, 2 straight ends
745052-001 Rear chassis fan, standard
745053-001 Speaker
745054-001 Fan sink for use in 400 MT and 490 MT models
745238-001 System board for use in 400 MT models with NetClone (includes replacement thermal material) (the People’s
Republic of China only)
745240-001 System board for use in 490 MT models with NetClone (includes replacement thermal material) (the People’s
Republic of China only)
745668-001 Intel Dual Band Wireless-N 7260 802.11 a/b/g/n (2x2) Wireless NIC
747910-001 System board for use in 480 G1 models without Windows 8 (includes replacement thermal material)
22 Chapter 3 Illustrated parts catalog

HP ProDesk 490 G1 Specifications

General

Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	8 MB
Processor cores	4
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Desktop series
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory voltage supported by processor	1.5 V
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	4x DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Maximum internal memory	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	1000 GB
Intel segment tagging	Enterprise, Small Business
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
On-board graphics card ID	0x412
Discrete graphics card model	NVIDIA® GeForce® GT 630
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2048 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	2 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
Bundled software	HP Client Security\\r HP Trust Circles Standard\\r HP Wireless HotSpot\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r CyberLink PowerDVD\\r CyberLink Power2Go\\r Buy Office
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Audio system	Realtek ALC221
Product type	PC
Motherboard chipset	Intel® H87
Scalability	1S
Processor code	SR149
Processor ARK ID	75122
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00
Power supply	300 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	402 mm
Width	182.8 mm
Height	357 mm
Weight	7140 g
