HP ProLiant DL120 Gen9 - Pcie Riser Board Slot Definitions

Component identification 11
Item Description Status
1
UID LED Solid blue = Activated
Flashing blue:
•
1 Hz/cycle per sec = Remote management
or firmware upgrade in progress
•
4 Hz/cycle per sec = iLO manual reboot
sequence initiated
•
8 Hz/cycle per sec = iLO manual reboot
sequence in progress
Off = Deactivated
2
NIC link LED Green = Network link
Off = No network link
3
NIC activity LED Solid green = Link to network
Flashing green = Network active
Off = No network activity
4
Power supply LED Solid green = Normal
Off = One or more of the following conditions
exists:
•
Power is unavailable
•
Power supply failed
•
Power supply is in standby mode
•
Power supply error
PCIe riser board slot definitions
Expansion
Slots
Riser board
options
Technology Bus
Width
Connector
Width
Form Factor Notes
1
PCIe riser PCIe 3.0 x16 x16 Low-profile —
2
PCIe riser PCIe 3.0 x8 x8 Low-profile Unavailable
when an x16
riser is installed
in slot 3
3
PCie riser
GPU
FlexibleLOM
PCIe. 3.0 x8
x16
x8
x8
x16
x8
Full-height/Half-length
GPU
FlexibleLOM
—
