Illustrated parts catalog 15
Illustrated parts catalog
In this section
Mechanical components ......................................................................................................................... 15
System components ................................................................................................................................ 18
Mechanical components
Item Description Spare part number
Customer self repair
(on page 5)
1 Access panel 398440-001 Mandatory
1
2 Bezel (see Miscellaneous plastics kit, item 25) — Mandatory
1
3
Serial label pull tab (see Miscellaneous plastics kit,
item 26)
— Mandatory
1
4 PCIe riser board assembly with bracket 398439-001 Optional
2
1
Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be
charged for the travel and labor costs of this service.
2
Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If,
however, you require that HP replace them for you, there may or may not be additional charges, depending on the
type of warranty service designated for your product.
3
No—Some HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires
that an authorized service provider replace the part. These parts are identified as "No" in the Illustrated Parts
Catalog.
1
Mandatory: Obligatoire—Pièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP
de remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés.
