Note:
Always follow safe electrostatic discharge practices.
Procedure
1. Power down the server according to Avaya's application instructions.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Remove any attached network cables.
4. Extend the server from the rack.
5. Remove the access panel.
6. Loosen the thumbscrew.
7. To replace the dual port PCIe 1GB NIC follow the expansion board removal instructions. See
PCIe riser card assembly on page 28.
8. Install the access panel.
9. Slide the server into the rack.
10. Connect the LAN segment cables.
11. Connect each power cord to the server.
12. Connect each power cord to the power source.
13. Power up the server.
Related links
NIC problems on page 25
PCIe riser card assembly
About this task
Use this procedure when adding or removing NIC cards.
Note:
Always follow safe electrostatic discharge practices.
Procedure
1. Power down the server according to Avaya's application instructions.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Extend the server from the rack.
