HP ProLiant DL360 Generation9

QuickSpecs
HPE ProLiant DL360 Generation9 (Gen9)
Configuration Information
- Factory Integrated Models
Page 23
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, Hewlett Packard Enterprise recommends the use of an Hewlett Packard Enterprise approved configurator. Contact your
local sales representative for information on configurable product offerings and requirements.
1. Factory Integrated Models must start with a CTO Server.
2. FIO indicates that this option is only available as a factory installable option.
3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives
ordered with the server.
4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.
Step 1: Base Configuration (choose one of the following configurable models)
CTO Server
HPE ProLiant DL360 Gen9 4LFF Configure-to-order
Server
HPE ProLiant DL360 Gen9 8SFF Configure-to-
order Server
SKU Number
755259-B21
755258-B21
Processor
2 (optional) x HPE Smart Socket Guide
DIMM Slots
24 DIMM slots for RDIMM, LRDIMM DDR4 Memory
Storage
Controller
HPE Dynamic Smart Array B140i
PCIe
2 PCIe 3.0 Slots: Slot 1, FH / ¾ Length; Slot 2, Low Profile
Drive Cage
4LFF Hot Plug
8SFF Hot Plug
Network
Controller
HPE Embedded 1Gb Ethernet 4-port 331i Adapter
Fans
5 standard hot plug fans, redundant
Management
iLO Management (standard), Intelligent Provisioning (standard)
USB
1 front, 2 internal, 2 rear
Ears
HPE Quick Release Ears
NOTE: 4LFF CTO Server includes 1 SATA Cable, option kit: 766213-B21, which attaches to the B140i controller.
NOTE: 8SFF CTO Server includes two 4 x Mini-SAS Cables, option kit: 766209-B21, which attaches to an optional HPE Smart
HBA H240ar or HPE Smart Array P440ar controller.
Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)
HPE Processors
E5-2600v4 Series Processors
HPE DL360 Gen9 Intel® Xeon® E5-2630Lv4 (1.8GHz/10-core/25MB/55W) FIO Processor Kit
818164-L21
HPE DL360 Gen9 Intel® Xeon® E5-2650Lv4 (1.7GHz/14-core/35MB/65W) FIO Processor Kit
818166-L21
HPE DL360 Gen9 Intel® Xeon® E5-2603v4 (1.7GHz/6-core/15MB/85W) FIO Processor Kit
818168-L21
HPE DL360 Gen9 Intel® Xeon® E5-2609v4 (1.7GHz/8-core/20MB/85W) FIO Processor Kit
818170-L21
HPE DL360 Gen9 Intel® Xeon® E5-2620v4 (2.1GHz/8-core/20MB/85W) FIO Processor Kit
818172-L21
HPE DL360 Gen9 Intel® Xeon® E5-2623v4 (2.6GHz/4-core/10MB/85W) FIO Processor Kit
818190-L21
HPE DL360 Gen9 Intel® Xeon® E5-2637v4 (3.5GHz/4-core/15MB/135W) FIO Processor Kit
818192-L21
HPE DL360 Gen9 Intel® Xeon® E5-2643v4 (3.4GHz/6-core/20MB/135W) FIO Processor Kit
818194-L21
HPE DL360 Gen9 Intel® Xeon® E5-2640v4 (2.4GHz/10-core/25MB/90W) FIO Processor Kit
818176-L21
HPE DL360 Gen9 Intel® Xeon® E5-2650v4 (2.2GHz/12-core/30MB/105W) FIO Processor Kit
818178-L21
HPE DL360 Gen9 Intel® Xeon® E5-2660v4 (2.0GHz/14-core/35MB/105W) FIO Processor Kit
818180-L21
HPE DL360 Gen9 Intel® Xeon® E5-2697Av4 (2.6GHz/16-core/40MB/145W) FIO Processor
Kit
818182-L21
