HP ProLiant DL360 Generation9

QuickSpecs
HPE ProLiant DL360 Generation9 (Gen9)
Memory
Page 54
DRAM Depth [bit]
512M
1G
512M
1G
1G
2G
2G
2G
DRAM Width [bit]
x8
x4
x8
x4
x4
x4
x4
x4
DRAM Density
4Gb
4Gb
4Gb
4Gb
4Gb
8Gb
8Gb
8Gb
CAS Latency
15-15-15
15-15-15
15-15-15
15-15-15
15-15-15
15-15-15
15-15-15
15-15-15
DIMM Native
Speed (MT/s)
2133
2133
2133
2133
2133
2133
2133
2133
SLOTS THAT CAN BE POPULATED
24 slot servers
24
24
24
24
24
24
24
24
MAXIMUM CAPACITY (GB)
96
192
192
384
768
384
768
1536
POPULATED DIMM SPEED (MT/s)
1 DIMM Per
Channel
2133
2133
2133
2133
2133
2133
2133
2133
2 DIMM Per
Channel
2133
2133
2133
2133
2133
2133
2133
2133
3 DIMM Per
Channel
1600
1600
1600
1600
1600
1866
1866
1866
DIMM slot and
configuration
diagram
DIMM slot and configuration diagrams
Basic memory slot & population diagram
•
Population order; start with "A" first, "B" second, "C" third, etc.
• When one processor is installed, install DIMMs in sequential alphabetic order: A, B, C, D, E, F.
• When two processors are installed, install DIMMs in sequential alphabetic order: CPU1-A, CPU2-A,CPU1-
B,CPU2-B,CPU1-C, CP2-C.
CPU 1
CPU 2
Slot #
Population order
Slot #
Population order
Chnl 3
1
C
1
C
Chnl3
2
G
2
G
3
K
3
K
CPU 1
CPU 2
Slot #
Population order
Slot #
Population order
Chnl 4
4
D
4
D
Chnl 4
5
H
5
H
6
L
6
L
CPU 1
CPU 2
Slot #
Population order
Slot #
Population order
Chnl 2
7
J
7
J
Chnl 2
8
F
8
F
9
B
9
B
CPU 1
CPU 2
