Removal and replacement procedures 39
Fan module
The server has eight fans. Install fans 1 and 2 only when processor 2 is installed. When only one
processor is installed, install the fan blanks in bays 1 and 2 ("Fan modules" on page 84).
To remove the component:
1. Extend the server from the rack (on page 26).
2. Remove the access panel ("Access panel" on page 27).
CAUTION: To avoid server shutdown, a fan must be replaced within 60 seconds of being
removed.
3. Remove the fan module.
The illustration shows fans 1 and 2 removed for a single-processor configuration.
To replace the component:
1. Install the fan module.
