HP ProLiant DL380 Generation9 (Gen9)
c04375627 – DA – 15034 North America — Version 7 — February 17, 2015
HP memory from previous generation servers is not compatible with the DL380 Gen9 Server. Certain HP
SmartMemory features such as memory authentication and enhanced performance may not be supported.
To realize the performance memory capabilities listed in this document, HP SmartMemory is required. For
additional information, please see the HP SmartMemory QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.html
For memory population rules and additional memory guidelines, please see the DL380 Gen9 user guide at
http://www.hp.com/support.
There are four (4) Memory channels per processor; eight (8) channels per 2 processor server.
There are three (3) DIMM slots for each memory channel; twenty four (24) total slots for 2 processor server.
Memory channels1 and 3 consists of the three (3) DIMMs that are furthest from the processor.
Memory channel 2 and 4 consists of the three (3) DIMMs that are closest to the processor.
Intel Gen9 Supported Memory Bandwidth for HP ProLiant Gen9 Intel® Xeon®E5-2600v3 Series Processor Family
Memory Bandwidth and Capacity
Registered Dimms (RDIMMs)
Unbuffered with
ECC DIMMs
(UDIMMs)
SLOTS THAT CAN
BE POPULATED
Memory Speed by
Processor Model
E5-2620v3, E5-2623v3, E5-2630v3, E5-2630Lv3, E5-
2640v3,
E5-2637v3, E5-2643v3, E5-2650v3, E5-2650Lv3, E5-
2660v3, E5-2667v3, E5-2670v3, E5-2680v3, E5-2683v3,
E5-2690v3, E5-2695v3, E5-2697v3, E5-2698v3, E5-
2699v3, E5-2687Wv3,
Standard and
Maximum Memory
Capacity (Pre-
configured Models)
Maximum Memory Plus
Optional Memory
Standard Memory Replaced
with Optional Memory
