Removal and replacement procedures 38
6.
Remove the hard drive backplane.
To replace the component, reverse the removal procedure.
PCI riser cage
To remove the component:
CAUTION: For proper cooling do not operate the server without the access panel, baffles,
expansion slot covers, or blanks installed. If the server supports hot-plug components, minimize
the amount of time the access panel is open.
1. Power down the server (on page 26).
2. Extend the server from the rack (on page 25).
3. Remove the access panel ("Access panel" on page 30).
4. Remove the PCI riser cage.
