HP ProLiant DL580 G7 - SPI Board Components

Component identification 15
SPI board components
Item Description
1
Mini SAS connectors (2)
2
SAS cache connector
3
TPM connector
4
Fan data connector
5
RMII connector
6
SD card slot
7
Battery
8
10Gb NIC connector
9
NIC cache connector
10
NIC 3 connector
11
NIC 1 connector
12
Video connector
13
Keyboard connector
14
USB connectors (2)
15
iLO 3 connector
16
Mouse connector
17
Serial connector
18
NIC 2 connector
19
NIC 4 connector
