Hardware options installation 43

IMPORTANT: The battery pack might have a low charge when installed. In this case, a POST

error message is displayed when the server is powered up, indicating that the battery pack is

temporarily disabled. No action is necessary on your part. The internal circuitry automatically

recharges the batteries and enables the battery pack. This process might take up to four hours.

During this time, the cache module functions properly, but without the performance advantage of

the battery pack.

NOTE: The data protection and the time limit also apply if a power outage occurs. When power

is restored to the system, an initialization process writes the preserved data to the hard drives.

To install the component:

1. Power down the server (on page 16).

2. Open or remove the tower bezel ("Remove the bezel" on page 17).

3. Remove the access panel (on page 18).

4. Install the storage controller, if not installed ("Installing expansion boards" on page 39).

5. Open the cache module latches.

6. Install the cache module on the controller.

Questions and Answers:

Need help?

Do you have a question about the HP ProLiant ML310 Generation 5p and is the answer not in the manual?

HP ProLiant ML310 Generation 5p Specifications

General

Processor Sockets	1
Chipset	Intel 3200
Memory Slots	4
Storage	SATA or SAS
Form Factor	Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon 3000 sequence, Dual-Core Intel Pentium, Intel Celeron
Memory	Maximum 8 GB PC2-6400E DDR2 SDRAM
Drive Bays	4 LFF SATA Hot-Plug or Non-Hot-Plug
Storage Controller	HP Smart Array E200i
RAID Support	RAID 0, 1
Optical Drive	Optional
Network	Embedded NC105i PCI Express Gigabit Server Adapter
