Table 14 Serial cable pinouts
DescriptionSignalPin
N/ANot supported1
N/ANot supported2
Transmit dataUART1_TXD3
Logic groundGND4
Logic groundGND5
Receive dataUART1_RXD6
N/ANot supported7
N/ANot supported8
AG default port mapping
Table 15 (page 42) lists the port mappings of F_Ports to N_Ports.
Table 15 AG default port mapping
Default port mappingN_PortsF_PortsTotal ports
0–4 mapped to 4040–470–3948
5–9 mapped to 41
10–14 mapped to 42
15–19 mapped to 43
20–24 mapped to 44
25–29 mapped to 45
30–34 mapped to 46
35–39 mapped to 47
42 Specifications
