Table 9 Power supply specifications (continued)
ValuesSpecification
the form of AC cycles, or multiple AC cycles greater than 10 ms and less
than 150 ms, must not exceed 15 A peak.
150 W at 12 VDCSingle power supply output
12.5 A at 12 VDCMaximum current
Both AC lines fusedInput line protection
110 W with all 48 ports populated with 16 Gb/s SWL optical mediaSystem power consumption
72 W with empty chassis and no optical media
Environmental requirements
Table 10 (page 40) lists the acceptable environmental ranges for both operating and nonoperating
(such as during transportation or storage) conditions.
Table 10 Environmental requirements
Acceptable range during nonoperationAcceptable range during operationCondition
-25º to 70ºC (-13º to 158ºF)0º to 40ºC (32º to 104ºF)Ambient
temperature
10% to 90% RH non-condensing, at 70ºC (158ºF)10% to 85% RH non-condensing, at 40ºC (104ºF)Humidity
0 to 12 km (39,370 ft) above sea level0 to 3 km (9,842 ft) above sea levelAltitude
33 G, 11 ms, half-sine wave, 3/e.g. Axis20 G, 6 ms, half-sine waveShock
2.0 G sine, 1.1 gms random, 5–500 Hz0.5 G sine, 0.4 gms random, 5–500 HzVibration
N/AMaximum - 71.36 cubic m/h (42 cubic ft/m)Airflow
Nominal - 59.47 cubic m/h (35 cubic f/m)
N/A338 BTU/hr (32-port configuration)Heat dissipation
375 BTU/hr (48-port configuration)
General specifications
Table 11 General specifications
DescriptionSpecification
F_Port, E_Port, M_Port, EX_Port, and D_PortConfigurable port types
Nonblocking shared-memory switchSystem architecture
PowerPC 440EPx at 667 MHzSystem processor
FC-PHANSI FC protocol
FC Class 2 and Class 3Modes of operation
Complies with FC-SW-3 Rev. 6.6Fabric initialization
Complies with FC-IP 2.3 of FCA profileFC-IP
768 Gb/sAggregate switch I/O bandwidth
Less than 700 ns with no contention (destination port is free)FC port-to-port latency
420 million frames per second (for Class 2, Class 3, and Class F frames for
the 48 port chassis)
Aggregate switching capacity
40 Specifications
