Item Component Spare part number

(1) Display assembly: 13.3-in, ultra wide aspect ratio, TouchScreen (includes display panel cable, microphones, hinges,

webcam, and wireless antenna cables and transceivers)

13.3-in, QHD, WLED, BrightView (2560×1440), UWVA, 2.55-mm display assembly 828823-001

13.3-in, FHD, WLED, BrightView (1920×1080), UWVA, 2.55-mm display assembly 828822-001

(2) Top cover 831855-001

(3) Keyboard (includes keyboard cable, keyboard backlight cable, and pointing stick cable):

For use in Belgium 801508-A41

For use in Canada 801508-DB1

For use in the Czech Republic and Slovakia 801508-FL1

For use in Denmark, Finland, and Norway 801508-DH1

For use in France 801508-051

For use in Germany 801508-041

For use in Greece 801508-151

For use in India (does not include pointing stick) 801508-D61

For use in Israel (does not include pointing stick) 801508-BB1

For use in Italy 801508-061

For use in Japan (does not include pointing stick) 801508-291

For use in Latin America 801508-161

For use in the Netherlands 801508-B31

For use in Portugal 801508-131

For use in Russia 801508-251

For use in Saudi Arabia 801508-171

For use in South Korea 801508-AD1

For use in Spain 801508-071

For use in Switzerland 801508-BG1

For use in Turkey 801508-141

For use in the United Kingdom and Singapore 801508-031

For use in the United States 801508-001

(4) Power connector cable 801513-001

(5) Audio jack board (includes cable) 828820-001

(6) TouchPad (includes cable) 801499-001

(7) Speakers (includes left and right speakers and cables) 801501-001

(8) Card reader board (includes cable) 828821-001

(9) System board (includes a graphics subsystem with UMA memory and replacement thermal material):

14 Chapter 3 Illustrated parts catalog

Questions and Answers:

Need help?

Do you have a question about the HP Spectre Pro x360 G2 and is the answer not in the manual?

HP Spectre Pro x360 G2 Specifications

General

Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Motherboard chipset	Intel SoC
Numeric keypad	No
Pointing device	Touchpad
Full-size keyboard	Yes
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	M.2, SATA
Storage media	SSD
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Operating system architecture	64-bit
Display surface	Gloss
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Native aspect ratio	16:9
On-board graphics card ID	1916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 520
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Battery capacity	56 Wh
Number of battery cells	3
Intel segment tagging	Home Office, Small Business
Number of built-in speakers	2
WWAN	Not installed
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Bus type	QPI
Stepping	D1
Tjunction	100 °C
Processor cache	3 MB
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-6200 series
Processor socket	LGA 1356 (Socket B2)
Processor threads	4
Processor codename	Skylake
Configurable TDP-up	25 W
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	2.8 GHz
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR2EY
Processor ARK ID	88193
Processor package size	42 X 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
HP segment	Business
HP Software provided	HP Wireless Hotspot
