TouchPad
Description Spare part number
TouchPad (includes cable) 801499-001
Before removing the TouchPad, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation,
turn the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 22).
5. Remove the battery (see Battery on page 23).
Remove the TouchPad:
1. Release the zero insertion force (ZIF) connector (1) to which the TouchPad cable is attached, and then
disconnect the TouchPad cable from the system board.
2. Remove the ve Phillips PM1.5×2.3 screws (2) that secure the TouchPad to the top cover.
