18 Components
Hard drive bay numbers
MSA2324fc
Rear panel components
MSA2324fc
1 Power supplies — AC
2 Power switches — AC
3 Host ports
4 CLI port
5 Ethernet port
6 Service port (used by service personnel only)
7 Expansion port
8 Optional FC controller
9 DC Power supply (2) — (DC model only)
10 Power switches — DC
1234567
1
9
2
8
10
