HP StorageWorks D2700 User Manual

DescriptionLED statusLED colorLED iconLED
No cable, no power, or port
not connected
Off
Greenn/a1. SAS Port Link The port is being identified by
an application client
Blinking
Healthy, active linkSolid
Normal, no errors detectedOff
Ambern/a2. SAS Port Error
Error detected by application
client
Blinking
Error, fault conditions detected
on the port by the I/O module
Solid
No cable, no power, enclosure
not detected
Off
n/an/a
3. 7–segment dis-
play
The enclosure box numberNumber
Not being identified or no
power
Off
Blue4. UID
Module is being identified,
from the management utility
Solid
No power or firmware malfunc-
tion
Off
Green5. Health Enclosure is starting up and not
ready, performing POST
Blinking
Normal, power is onSolid
Normal, no fault conditionsOff
Amber6. Fault
A fault of lesser importanceBlinking
A fault of greater importance,
I/O failed to start
Solid
D2600/D2700 Disk Enclosure User Guide 17

HP StorageWorks D2700 Specifications

General

Form Factor	2U
Host Interface	6 Gb/s SAS
Redundant Power Supplies	Yes
Drive Type	SAS/SATA
RAID Support	Depends on the connected controller
Compatibility	HP ProLiant servers
Cooling	Redundant fans
Enclosure Type	Rack-mounted
