Product Overview
18 NAS b2000 v2 Quick Start Guide
Note: * Included with NAS b2000 v2 external model only.
Table 2: Rear Panel Connectors
Item Description
1 PCI expansion slots
2 Serial connector (teal)
3 Integrated Lights-Out (iLO Eth)
4 Mouse connector (PS/2) (green)
5 Power connectors
6 Keyboard connector (PS/2) (purple)
7 RJ-45 connector for NIC 1 (Eth0)
8 RJ-45 connector for NIC 1 (Eth1)
9 USB connectors (2) (black)
- Video connector (blue)
q VHDCI SCSI connector (SCSI port 1)
w Smart Array 5304 controller *
