HP StoreOnce 5100

Figure 17 Cabling showing five Capacity Upgrade Kits below the head server
1
2
3
4 1
5
6
4
4
1
iLO
PS2
6
7
8
1
2
3
4
5
JBOD22JBOD11
JBOD44JBOD33
SAS connector on RAID controller on head unit6JBOD55
P2 connector on I/O module (SAS OUT to next
expansion shelf)
8P1 connector on I/O module (SAS IN from head
unit or previous expansion shelf)
7
StoreOnce 5100 System with Capacity Expansion 59
