Bottom: 8 screws
Figure 7-57 Removing the middle frame screws – bottom
11. Disengage the tabs that secure the bezel to the computer, as follows.
Left: 2 tabs
Right: 2 tabs
Figure 7-58 Middle frame tabs
12. As far as the display cable allows, separate the computer assembly from the display/bezel
assembly.
CAUTION: Be careful not to separate the computer and panel too far before disconnecting the
display cable.
88 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
