2 System Features
System Board & Backplane Layout
Celeron-based Models (VLi 8SF only)
DIMM1
DIMM2
Memory Slots
Processor Socket
System Board Switches
Display
Kbd
SDRAM
Battery Socket
USB
SDRAM
440 ZX
Video Chip
Crystal
Audio
Intel PCI
Set
PIIX4e
Serial
Connector B
Serial
Connector A
SDRAM
SDRAM
The parallel port and
mouse connector are
located above Serial
Port A, the Display
Connector and the
Keyboard Connector,
respectively.
