System Overview
12 product description
Specifications
Physical Characteristics
NOTE
Operating temperature and humidity ranges may vary depending on the mass storage devices installed. High humidity
levels can cause improper operation of disk drives. Low humidity ranges can aggravate static electricity problems and
cause excessive wear of the disk surface.
The power consumption and acoustics figures given in the tables above are valid for the standard configuration as shipped.
For more information, refer to the product’s data sheet at HP’s web site: www.hp.com/desktops.
When the computer is turned off with the power button on the front panel, the power consumption falls below 10W, but
it is not zero. The special on/off method used by these computers considerably extends the lifetime of the power supply.
To reach zero power consumption in “off” mode, either unplug the power outlet or use a power block with a switch.
Environmental Specifications
Vectra XE310 Characteristics
Weight (configuration with 1 CD-ROM drive,
excluding keyboard and display)
10 kilograms (22 pounds)
Dimensions 38.0 cm (Depth) by 21.0 cm (Width) by 39.0 cm (Height)
(14.96 inches by 8.27 inches by 15.35 inches)
Footprint 0.068 m
2
(0.73 sq ft)
Acoustic noise emission (ISO 7779)
Operating (idle)
Sound pressure level at operator position
LpA
≤
35 dBA
Power Supply
Input voltage (voltage selection switch):
Input frequency:
100-127 V 4A, 200-240 V 2A
50/60Hz
Power consumption (115 / 60Hz and 230 / 50 Hz)
Max
Operating
Suspend
Off
Windows XP
62W
40W
≤
5W
≤
5W
Available minimum output power 149W
Storage Humidity 8% - 85% (relative)
Environmental Specifications (System Processing Unit, with Hard Disk)
Operating Temperature +10
°
C to +35
°
C (+50
°
F to 95
°
F)
Storage Temperature -40°F to +70°F (-40°C to +158°C)
Operating Humidity 15% to 80% (relative)
Storage Humidity 8% to 85% (relative), non-condensing at 40°C (104°F)
Operating Altitude 10000ft (3100m) max
Storage Altitude 15000ft (4600m) max
