System Features
product description 15
Architectural View
The following diagram shows the XE310 Series 2 Intel 815EG Chip architecture:
Main Memory
There are two 168-pin DIMM slots on the system board for installing main memory. You can install
133MHz SDRAM modules, these are available in 64, 128 and 256MB memory modules. You can install a
maximum of 512MB (2 x 256MB modules).
You can only use non-ECC memory modules.
ICH2 chip
Audio
AD1885
Intel Pentium III Processor
or
Intel Celeron Processor
Intel 815EG
Main Memory
133MHz SDRAM
3 PCI Slots
Memory Bus
Host Bus
PCI Bus
Super I/O
Serial/Parallel/FDD/PS2
Flash BIOS
Hard Disk
CD-ROM
2 IDE Drives
DVD/CD-RW/Zip
Hard Disk
2 UATA 100 Disks
Integrated Intel
82815 graphics
controller
Intel LAN
4 USB Slots
Monitor
Output
VGA
