HP VH240a User Manual

Setting up the monitor 5
NOTE: The monitor automatically determines which inputs have valid video signals. The inputs can be
selected by pressing the Menu button to access the on-screen display (OSD) menu and selecting Input
Control.
Connect one end of the VGA cable to the VGA port on the rear of the monitor and the other end to the
source device.
VGA
Connect one end of an HDMI cable to the HDMI port on the rear of the monitor and the other end to the
source device. cable not included.
HDMI

HP VH240a Specifications

General

3D	No
Pixel pitch	0.274 x 0.274 mm
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	296.4 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switch	Yes
Pivot angle	0 - 90 °
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
Product color	Black
Country of origin	China
Market positioning	-
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	28 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	19 W
RMS rated power	4 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	218 mm
Width (with stand)	539 mm
Height (with stand)	499 mm
Depth (without stand)	46 mm
Height (without stand)	323 mm
Weight (without stand)	4660 g
