HP VH240a User Manual

Setting up the monitor 9
The monitor automatically scans the signal inputs for an active input and uses that input for the screen.
HP watermark and image retention policy
The IPS monitor models are designed with IPS (In-Plane Switching) display technology which provides
ultrawide viewing angles and advanced image quality. IPS monitors are suitable for a wide variety of
advanced image quality applications. This panel technology, however, is not suitable for applications that
exhibit static, stationary, or fixed images for long periods of time without the use of screen savers. These
types of applications may include camera surveillance, video games, marketing logos, and templates that
are displayed on the screen for a prolonged period of time. Static images may cause image retention damage
that could look like stains or watermarks on the monitor’s screen.
Removing the monitor stand
You can remove the monitor from the stand to mount the monitor to a wall, a swing arm, or other mounting
fixture.
CAUTION: Before beginning to disassemble the monitor, be sure that the monitor is turned off and all
cables are disconnected.
1. Disconnect and remove all cables from the monitor.
2. Position the monitor facedown on a flat surface covered by a clean, dry cloth.
3. Press down on the release latch (1).
4. Slide the stand out of the slot on the monitor (2).
2
1
Mounting the monitor
The monitor can be attached to a wall, swing arm, or other mounting fixture.
NOTE: This apparatus is intended to be supported by a UL or CSA Listed wall-mount bracket.
CAUTION: This monitor supports the VESA industry standard 100 mm mounting holes. To attach a third-
party mounting solution to the monitor, four 4 mm, 0.7 pitch, and 10 mm screws are required. Longer screws
must not be used because they may damage the monitor. It is important to verify that the manufacturer’s
mounting solution is compliant with the VESA standard and is rated to support the weight of the monitor. For
best performance, it is important to use the power and video cables provided with the monitor.
1. Remove the monitor from the stand. Removing the monitor stand on page 9

HP VH240a Specifications

General

3D	No
Pixel pitch	0.274 x 0.274 mm
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	296.4 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switch	Yes
Pivot angle	0 - 90 °
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
Product color	Black
Country of origin	China
Market positioning	-
Sustainability certificates	EPEAT Silver, ENERGY STAR
AC input voltage	100 - 240 V
Power consumption (off)	0.3 W
Annual energy consumption	28 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	19 W
RMS rated power	4 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	218 mm
Width (with stand)	539 mm
Height (with stand)	499 mm
Depth (without stand)	46 mm
Height (without stand)	323 mm
Weight (without stand)	4660 g
