HP X27i

13
4
1. Remove lamp wire from
panel
2. Remove Lens cable
from panel
3. Disassemble Lens BD
from MF
4. Remove Lens cable
from Lens BD
5. Remove Ctrl cable from
panel
6. Disassemble Ctrl BD
from MF
7. Remove CTRL cable
from CTRL BD
5
1. Remove 2 conduct tape
from SHD
2. Disassemble SHD from
panel
3. Unlock 9 screws
Screw-
driver
6.5-
7.5Kg
6
1. Remove 4 FFC cable
from panel
7
1. Disassemble MF from
panel
2. Remove 2 mylar from
panel
SPS BD
IF BD
Remove 2 mylar
IF BD
