HP Z230 User Manual

●
Rear USB Ports
●
Accessory USB Ports
Slot Security Allows you to Enable/Disable Option ROM Download for each slot. Selective disabling of Option
ROM downloads can help manage limited Option ROM space. Limit PCIe Frequency to Gen1,
Gen2, Gen3. Runs slot at Gen1, Gen2, or Gen3 frequency.
Network Boot Enables/disables the computer’s ability to boot from an operating system installed on a network
server. (Feature available on NIC models only; the network controller must be either a PCI
expansion card or embedded on the system board.) Default is enabled.
System IDs Allows you to set:
●
Asset tag (18-byte identifier), a property identification number assigned by the company to
the computer.
●
Ownership tag (80-byte identifier) displayed during POST.
●
Universal Unique Identifier (UUID) number. The UUID can only be updated if the current
chassis serial number is invalid. (These ID numbers are normally set in the factory and are
used to uniquely identify the system.)
●
Keyboard locale setting for System ID entry.
Master Boot Record
Security
Enables/disables Master Boot Record (MBR) security.
The MBR contains information needed to successfully boot from a disk and to access the data
stored on the disk. Master Boot Record Security may prevent unintentional or malicious changes
to the MBR, such as those caused by some viruses or by the incorrect use of certain disk utilities.
It also allows you to recover the "last known good" MBR, should changes to the MBR be detected
when the system is restarted.
When MBR Security is enabled, the BIOS prevents any changes being made to the MBR of the
current bootable disk while in MS-DOS or Windows Safe Mode.
NOTE: Most operating systems control access to the MBR of the current bootable disk; the
BIOS cannot prevent changes that may occur while the operating system is running.
Restores the backup Master Boot Record to the current bootable disk. Default is disabled.
Only appears if all of the following conditions are true:
●
MBR security is enabled
●
A backup copy of the MBR has been previously saved
●
The current bootable disk is the same disk from which the backup copy was saved
CAUTION: Restoring a previously saved MBR after a disk utility or operating system has
modified the MBR, may cause the data on the disk to become inaccessible. Only restore a
previously saved MBR if you are confident that the current bootable disk MBR has been corrupted
or infected with a virus.
System Security (these
options are hardware
dependent)
●
Data Execution Prevention—(Enable/Disable). Helps prevent operating system security
breaches. Default is enabled.
●
SVM CPU Virtualization—(Enable/Disable). Controls the virtualization features of the
processor. Changing this setting requires hat you turn off the computer and then turn it back
on. Default is disabled.
●
Virtualization Technology (VTx)—(Enable/Disable). Controls the virtualization features of the
processor. Changing this setting requires that you turn off the
computer and then turn it back
on. Default is disabled.
●
Virtualization Technology Directed I/O (VTd)— (Enable/Disable). Controls virtualization DMA
remapping features of the chipset. Changing this setting requires that you turn off the
computer and then turn it back on. Default is disabled.
●
Trusted Execution Technology—(Enable/Disable). Controls the underlying processor and
chipset features needed to support a virtual appliance. Changing this setting requires that
Computer Setup (f10) Utility 29

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
