Chassis components
The following figure shows the chassis components of a typical tower workstation layout. Drive
configurations can vary.
Item Description Item Description
1 Side access panel 6 Slim optical drive
2 Power supply 7 Front bezel
3 Chassis 8 Hard drive (HDD)
4 Optical drive 9 Solid-state drive (SSD)
5 Optional media reader or
second hard drive
10 System board
Tower workstation components 13
