Chassis components
For complete and current information on supported accessories and components for the computer, go
to
http://partsurfer.hp.com.
The following image shows the components of a typical SFF computer layout. Drive configurations
can vary.
1 Access panel 6 Optical drive
2 Power supply 7 Hard drive
3 System board 8 Optional memory card reader or second hard drive
4 Chassis 9 Front bezel
5 Airflow guide
Small form factor workstation components 5
