HP Z400 User Manual

Table 6-8 Diagnostic lights and audible codes (continued)
Activity Possible cause Recommended action
Red Power LED blinks four
times, once every second,
followed by a two-second
pause. Four beeps.
Power failure (power supply
is overloaded)
CAUTION: Internal components might be powered even when the
workstation is off. To prevent damage, disconnect the workstation power
cord before you remove a component.
1. Open the access panel and ensure that all power connections (24-
pin Main, 4-pin CPU) are secure on the system board.
2. Check if a device is causing the problem by removing all attached
devices (such as hard, diskette, or optical disk drives, and
expansion cards.) Power on the computer. If the system enters the
POST, power off and replace one device at a time; repeat this
procedure until failure occurs. Replace the device that is causing the
failure. Continue adding devices one at a time to ensure all devices
are functioning properly.
3. (For computers with a BIST LED on the rear panel) Check the power
supply functionality:
a. Disconnect the AC power.
b. Disconnect ALL internal power supply cables.
c. Plug in the AC power.
d. Power on the computer.
●
If the power supply fan spins and the BIST LED lights, the
power supply is functional. The problem might be on the
system board. Contact HP for assistance.
●
If the power supply fan does not spin or the BIST LED
does not light, the problem might be in the power supply.
Contact HP for assistance.
Red Power LED blinks five
times, once every second,
followed by a two-second
pause. Five beeps.
Pre-video memory error CAUTION: Internal components might be powered even when the
workstation is off. To prevent damage, disconnect the workstation power
cord before you remove a component.
1. Reseat DIMMs.
2. Replace DIMMs one at a time to isolate faulty module.
3. Replace third-party memory with HP memory.
4. The problem might be on the system board. Contact HP for
assistance.
Red Power LED blinks six
times, once every second,
followed by a two-second
pause. Six beeps.
Pre-video graphics error. CAUTION: Internal components might be powered even when the
workstation is off. To prevent damage, disconnect the workstation power
cord before you remove a component.
1. Reseat the graphics card.
2. Verify the graphics auxiliary power cable is connected (if
applicable).
3. The problem might be on the graphics card. Contact HP for
assistance.
ENWW
Diagnostic codes and errors
197

HP Z400 Specifications

General

Bus type	QPI
Processor cache	4 MB
Processor cores	2
Processor model	W3503
System bus rate	4.8 GT/s
Processor socket	-
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Number of processors installed	1
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Audio system	Realtek ALC262
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	6x DIMM
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1066 MHz
Memory layout (slots x size)	- GB
Graphics card	Quadro 600
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
HDD speed	- RPM
RAID levels	0, 1, 5, 10
HDD capacity	500 GB
HDD interface	SATA II
Storage media	HDD
Display included	No
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Minitower
Country of origin	China
Number of 5.25\" bays	3
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
Power supply	475 W
Processor ARK ID	40800
Processor package size	42.5 x 45 mm
Supported instruction sets	SSE4.2

Weight and Dimensions

Depth	455.3 mm
Width	167.9 mm
Height	450.2 mm
Weight	13500 g
